Base class actions that do have a finite time duration. More...

#include <CCAction.h>

Inheritance diagram for CCFiniteTimeAction:

Public Member Functions
	CCFiniteTimeAction ()
	CCFiniteTimeAction ()
virtual	~CCFiniteTimeAction ()
float	getDuration (void)
	get duration in seconds of the action More...

var	getDuration ()
	get duration in seconds of the action More...

local	getDuration ()
	get duration in seconds of the action More...

void	setDuration (float duration)
	set duration in seconds of the action More...

var	setDuration ( var duration)
	set duration in seconds of the action More...

local	setDuration ( local duration)
	set duration in seconds of the action More...

virtual CCFiniteTimeAction *	reverse (void)
	returns a reversed action More...

local	reverse ()
	returns a reversed action More...

Public Member Functions inherited from CCAction
	CCAction (void)
	ctor ()
	CCAction ()
virtual	~CCAction (void)
const char *	description ()
virtual CCObject *	copyWithZone (CCZone *pZone)
virtual bool	isDone (void)
	return true if the action has finished More...

var	isDone ()
	return true if the action has finished More...

local	isDone ()
	return true if the action has finished More...

virtual void	startWithTarget (CCNode *pTarget)
	called before the action start. It will also set the target. More...

var	startWithTarget ( var pTarget)
	called before the action start. It will also set the target. More...

local	startWithTarget ( local pTarget)
	called before the action start. It will also set the target. More...

virtual void	stop (void)
	called after the action has finished. More...

var	stop ()
	called after the action has finished. More...

local	stop ()
	called after the action has finished. More...

virtual void	step (float dt)
	called every frame with it's delta time. DON'T override unless you know what you are doing. More...

virtual void	update (float time)
	called once per frame. More...

local	update ( local time)
	called once per frame. More...

CCNode *	getTarget (void)
void	setTarget (CCNode *pTarget)
	The action will modify the target properties. More...

var	setTarget ( var pTarget)
	The action will modify the target properties. More...

local	setTarget ( local pTarget)
	The action will modify the target properties. More...

CCNode *	getOriginalTarget (void)
local	getOriginalTarget ()
void	setOriginalTarget (CCNode *pOriginalTarget)
	Set the original target, since target can be nil. More...

int	getTag (void)
var	getTag ()
local	getTag ()
void	setTag (int nTag)
var	setTag ( var nTag)
local	setTag ( local nTag)
Public Member Functions inherited from CCObject
	CCObject (void)
virtual	~CCObject (void)
void	release (void)
void	retain (void)
CCObject *	autorelease (void)
CCObject *	copy (void)
bool	isSingleReference (void) const
unsigned int	retainCount (void) const
virtual bool	isEqual (const CCObject *pObject)
virtual void	acceptVisitor (CCDataVisitor &visitor)

Protected Attributes
float	m_fDuration
	duration in seconds More...

Protected Attributes inherited from CCAction
CCNode *	m_pOriginalTarget
CCNode *	m_pTarget
	The "target". More...

var	m_pTarget
	The "target". More...

local	m_pTarget
	The "target". More...

int	m_nTag
	The action tag. More...

Protected Attributes inherited from CCObject
unsigned int	m_uReference
unsigned int	m_uAutoReleaseCount

Additional Inherited Members
Static Public Member Functions inherited from CCAction
static CCAction *	create ()
	Create an action. More...

var	create ()
	Create an action. More...

local	create ()
	Create an action. More...

Public Attributes inherited from CCObject
unsigned int	m_uID
int	m_nLuaID

Detailed Description

Base class actions that do have a finite time duration.

Possible actions:

An action with a duration of 0 seconds
An action with a duration of 35.5 seconds

Infinite time actions are valid

Constructor & Destructor Documentation

CCFiniteTimeAction ( )

inline

var ctor ( )

inline

local CCFiniteTimeAction ( )

inline

virtual ~CCFiniteTimeAction ( )

inlinevirtual

Member Function Documentation

float getDuration ( void )

inline

get duration in seconds of the action

var getDuration ( )

inline

get duration in seconds of the action

local getDuration ( )

inline

get duration in seconds of the action

virtual CCFiniteTimeAction* reverse ( void )

virtual

returns a reversed action

Reimplemented in CCAnimate, CCReverseTime, CCDelayTime, CCTintBy, CCFadeOut, CCFadeIn, CCBlink, CCScaleBy, CCBezierBy, CCEaseBackInOut, CCEaseBackOut, CCJumpBy, CCEaseBackIn, CCEaseBounceInOut, CCSkewBy, CCEaseBounceOut, CCEaseBounceIn, CCEaseBounce, CCMoveBy, CCEaseElasticInOut, CCRotateBy, CCEaseElasticOut, CCEaseElasticIn, CCEaseElastic, CCSpawn, CCEaseSineInOut, CCEaseSineOut, CCFlipY, CCEaseSineIn, CCRepeatForever, CCEaseExponentialInOut, CCFlipX, CCCardinalSplineBy, CCEaseExponentialOut, CCDeccelAmplitude, CCEaseExponentialIn, CCRepeat, CCRemoveSelf, CCEaseInOut, CCAccelAmplitude, CCCardinalSplineTo, CCEaseOut, CCAccelDeccelAmplitude, CCSequence, CCHide, CCEaseIn, CCEaseRateAction, CCShow, CCActionInterval, CCProgressFromTo, CCActionTween, CCActionCamera, CCActionInstant, CCActionEase, and CCGridAction.

var reverse ( )

virtual

returns a reversed action

Reimplemented in CCAnimate, CCReverseTime, CCDelayTime, CCTintBy, CCFadeOut, CCFadeIn, CCBlink, CCScaleBy, CCBezierBy, CCEaseBackInOut, CCEaseBackOut, CCJumpBy, CCEaseBackIn, CCEaseBounceInOut, CCSkewBy, CCEaseBounceOut, CCEaseBounceIn, CCEaseBounce, CCMoveBy, CCEaseElasticInOut, CCRotateBy, CCEaseElasticOut, CCEaseElasticIn, CCEaseElastic, CCSpawn, CCEaseSineInOut, CCEaseSineOut, CCFlipY, CCEaseSineIn, CCRepeatForever, CCEaseExponentialInOut, CCFlipX, CCCardinalSplineBy, CCEaseExponentialOut, CCDeccelAmplitude, CCEaseExponentialIn, CCRepeat, CCRemoveSelf, CCEaseInOut, CCAccelAmplitude, CCCardinalSplineTo, CCEaseOut, CCAccelDeccelAmplitude, CCSequence, CCHide, CCEaseIn, CCEaseRateAction, CCShow, CCActionInterval, CCProgressFromTo, CCActionTween, CCActionCamera, CCActionInstant, CCActionEase, and CCGridAction.

local reverse ( )

virtual

returns a reversed action

Reimplemented in CCAnimate, CCReverseTime, CCDelayTime, CCTintBy, CCFadeOut, CCFadeIn, CCBlink, CCScaleBy, CCBezierBy, CCEaseBackInOut, CCEaseBackOut, CCJumpBy, CCEaseBackIn, CCEaseBounceInOut, CCSkewBy, CCEaseBounceOut, CCEaseBounceIn, CCEaseBounce, CCMoveBy, CCEaseElasticInOut, CCRotateBy, CCEaseElasticOut, CCEaseElasticIn, CCEaseElastic, CCSpawn, CCEaseSineInOut, CCEaseSineOut, CCFlipY, CCEaseSineIn, CCRepeatForever, CCEaseExponentialInOut, CCFlipX, CCCardinalSplineBy, CCEaseExponentialOut, CCDeccelAmplitude, CCEaseExponentialIn, CCRepeat, CCRemoveSelf, CCEaseInOut, CCAccelAmplitude, CCCardinalSplineTo, CCEaseOut, CCAccelDeccelAmplitude, CCSequence, CCHide, CCEaseIn, CCEaseRateAction, CCShow, CCActionInterval, CCProgressFromTo, CCActionTween, CCActionCamera, CCActionInstant, CCActionEase, and CCGridAction.

void setDuration ( float duration)

inline

set duration in seconds of the action

var setDuration ( var duration)

inline

set duration in seconds of the action

local setDuration ( local duration)

inline

set duration in seconds of the action

Member Data Documentation

float m_fDuration

protected

duration in seconds

var m_fDuration

protected

duration in seconds

local m_fDuration

protected

duration in seconds

The documentation for this class was generated from the following file:

/Users/cocos2d/MyWork/cocos2d-x/cocos2dx/actions/CCAction.h
